Fish Feed Processing Machine

Fish Feed Processing Machine

APPLICATION: Fish Feed Industry
CAPACITY: 0.6-30T/H
MAIN POWER: 22-315KW
MODEL: SZLH

Fish pellet feed has the advantages of uniform nutrient distribution, high digestibility, easy storage and no automatic classification, etc., and it is increasingly widely used in the aquaculture industry. Pelleting by fish feed making machine is an important link in the fish feed production process of pellet feed, which directly affects the quality of pellet feed.

Technical Features Of Fish Feed Processing Machine

  • 1.The fish feed processing machine adopts advanced hole layout technology and die hole structure make pellets uniform and smooth.
  • 2. Long service life, mould and gear>5000h. The fish food making machine can process fast sinking feed with about 30% starch.
  • 3. The fish feed production machine can produce 100% floating feed and 100% sinking feed only with two-layer and three-layer conditioner.
  • 4.The fish food production machine can reduce the dependence of feed formula and save the cost of raw materials.
  • 5. Precise and unique fish food processing machine ring die pelletizing structure increases oil content up to 12%.

Applications Of Fish Feed Processing Machine

  • The feed industry is the most industrialized industry in agriculture. It is the link that connects the planting industry, breeding industry, and animal product processing industry, and plays a pivotal role in agriculture. In the feed industry, the production technology of aquatic fish feed is very different from the traditional processing technology of livestock and poultry feed.
  • According to the characteristics of the variety of aquatic fish feeds, large changes in raw materials, high requirements for grinding fineness and poor material fluidity, the design of the production process generally adopts secondary grinding and mixing of secondary ingredients to complete the processing of powdered raw materials; and pressed by the fish feed pellet making machine into shape, and then the pellet for fish is processed into the finished product packaging system through drying, grease spraying, cooling and screening and other fish feed production processes.
  • Fish pellet feed has the advantages of uniform nutrient distribution, high digestibility, easy storage and no automatic classification, etc., and it is increasingly widely used in the aquaculture industry. Pelleting by fish feed processing machine is an important link in the fish feed making process of pellet feed, which directly affects the quality of pellet feed.
  • Reducing fish feed processing machine wear and power consumption, reducing production costs, ensuring pelleting quality and increasing pelleting output are the goals that fish feed companies and fish feed manufacturers pursue in the fish feed making process of producing pellets.

Parameter And Model Of Fish Feed Processing Machine

Model Capacity(TPH) Main Motor Power(kw) Feeder Motor Power(kw) Conditioner Power(kw) Dia.of Ring Die(mm) Final Pellet(mm)
SZLH250 0.6-1.4 22 0.75 1.5 250 1.5~12
SZLH320 1.8-2.8 37 1.5 2.2 320 1.5~12
SZLH350 3-5 55 1.5 3 350 1.5~12
SZLH420 4.8-8.5 90 1.5 7.5 420 1.5~12
SZLH508 6-12.5 132 2.2 11 508 1.5~12
SZLH558 9-17.5 180/200 2.2 11 558 1.5~12
SZLH558D 8.4-15.5 160/180/200 1.5 7.5 558 1.5~12
SZLH678 12-21 220/250 2.2 11 678 1.5~12
SZLH678D 9-17.5 200/220/250 2.2 11 673 1.5~12
SZLH768 15-28 280/315 2.2 11 768 1.5~12
SLZH858 15-30 280/315 2.2 15 858 1.5~12
Fish feed making machine price: 10000-100000USD.
